THÔNG SỐ KỸ THUẬT:
| Sn | 1700 VA | 2200 VA | 3300 VA |
| Pn | 1350 W | 1800 W | 2700 W |
| Input / output | 1/1 | ||
| Input | |||
| Rated voltage | 230 V | ||
| Voltage tolerances | 161 V ±4% (selecting wide mode) -276 V ±4% | ||
| Rated frequency | 50 / 60 Hz with automatic selection | ||
| Mains connection | IEC320-C14 (10 A) | IEC320-C20 (16 A) | |
| Output | |||
| Automatic Voltage Regulation (AVR) | The AVR increases (boost 1) the output voltage by 14% | ||
| when the input voltage drops below 90% of the nominal value. | |||
| The AVR decreases (bucks) the output voltage by 12% | |||
| when the input voltage rises above 106% of the nominal value. | |||
| Rated voltage | 230 V ±5% | ||
| Rated frequency | 50/60 Hz ±0.1% | ||
| Power factor | 0.9 | 0.9 | 0.9 |
| @ 1500 VA | @ 2000 VA | @ 3000 VA | |
| Wave form | Sine wave | ||
| Protection | Normal Mode: overload (110% for 3 minutes) | ||
| Battery Mode: overload (110% for 30 seconds); shortcircuit protected | |||
| Sockets | 8 (10 A) x IEC 320 | 8 (10 A) x IEC 320 | |
| 1 (16 A) x IEC 320 | |||
| Batteries | |||
| Type | Sealed lead-acid maintenance free – expected life 3/5 years | ||
| Back-up time (1) | 6 min | 8 min | 6 min |
| Communication | |||
| Interface | RS232 – USB | ||
| Ethernet adapter | NET VISION (TCP/IP & SNMP) optional card | ||
| Local communication software | Local View | ||
| Data line protection | NTP data line suppressor: RJ45 10 Base T | ||
| UPS Cabinet | |||
| Dimensions W x D x H | 440 x 436 x 87 mm | 440 x 608 x 87 mm | |
| Weight | 18 kg | 28.2 kg | 31.5 kg |
| Standards | |||
| Safety | IEC/EN 62040-1, AS 62040.1.1, AS 62040.1.2 | ||
| EMC | IEC/EN 62040-2, AS 62040.2 | ||
| Product declaration | CE, RCM (E2376) | ||
