THÔNG SỐ KỸ THUẬT:
| MODEL | PWR33 OL MODEL 10 | PWR33 OL MODEL 20 | PWR33 OL MODEL 30 |
| Power (kVA) | 10 | 20 | 30 |
| THDI Power Factor | >0,99 / < %5 | ||
| THDi Current Harmonic | <%3 Linear loads / < %5 Dynamic loads | ||
| Voltage | 380/400/415 VAC 3-Ph + N + Ground ±%20 ( 277-485 Vac range %100 without deration) | ||
| Frequency Ranges | 50/60 Hz auto sense , frequency range 40 Hz / 70 Hz | ||
| Bypass Voltages | 380/400/415 VAC 3-Ph +N,-%40/+%15 | ||
| Protections | Frequency out of tolerances, input power limitations, PFC | ||
| Output | |||
| Power (kVA) | 9 | 18 | 27 |
| Power Factor | 0,9 | ||
| Voltage | 380/400/415 VAC 3-Ph + N + Ground ±%1 adjustable | ||
| Frequency synchronisation | 45~55 Hz or 55~65 Hz synchronisation ranges with mains | ||
| Frekans toleransı | 50 / 60 Hz ±%0.1 on battery mode | ||
| Wave Form | Pure sine Wave | ||
| Efficiency (%100 load) | >94% | ||
| Crest Factor | crest factor ratio 3: 1 | ||
| Overload Capacities | %0 – %102 yükte sürekli , %102 – %125 yükte 10dk , %125 – %150 yükte 1dk , >%150 yükte 0.5 sn | ||
| Protections | intelligent short circuit protection,voltage out of range protection , DC out of range protection,over temp | ||
| THDv ( %100 Linear loads) | <%2 Lineer yüklerde / <%5 dinamik yüklerde / <%2 Linear loads / <%5 dynamic loads | ||
| Battery | |||
| Batteyr Type | Non maintenanced VRLA / AGM, JEL , Ni-Cd | ||
| DC bar Voltages | 240 Vdc | ||
| Number of Batteries | 20 x 12V akü /20 x 12V battery | ||
| Charging Voltages | 270 Vdc | ||
| End of Discharge voltahes | 192 VDC | ||
| Internal batteries | Dahili 20 x 9Ah | Dahili 40 x 9Ah | Dahili 60 x 9Ah |
| Additional internal capacity | Dahili 60 x 9Ah ‘e kadar | Dahili 60 x 9Ah ‘e kadar | Dahili 60 x 9Ah ‘e kadar |
| Battery ambient temp | 25ºC | ||
| Protections | audible alarm, batteyr fuses, charge current limitation, optional temp con- trolled charging current | ||
| Battery Tests | Programmable battery test | ||
| General | |||
| Standards | IEC/EN 62040-2 EMC, IEC/EN 61000-4-2 ESD , IEC/EN 61000-4-3 RS , IEC/EN 61000-4-4 EFT , IEC/EN 61000-4-5 SURGE | ||
| User interface | LCD panel, 3 button, Buzzer, LED | ||
| Informations on LCD | Ph-N/Ph-Ph voltages,Ph-N/Ph-Ph currents,Power kVA kW/ Alarms, Errors, configurations, Alarms | ||
| Alarms | Battery mode , Battery low level , Fan error | ||
| Communication | RS232 serial port, RS 485 , SNMP , Dry relay contact | ||
| External inputs | REPO remote emergency Power Off | ||
| Software | Windows’ 98 / 2000 / 2003 /XP / Vista / 2008 / 7 / 8 / 10 | ||
| Alarm logs | Standard; time & month 192 event | ||
| Protections | over temp, over current,over voltage, surge | ||
| Ambient temperature | 0ºC – 40ºC | ||
| Protection Class | IP20 | ||
| Humidity- Altitude | %90 max (non condensed / < 1000m above sea level | ||
| Noisy Level | < 56dBA | < 57dBA | <59dBA |
| Weight (kg) | 20x9Ah ile 115 Kg/40x9Ah ile 155 Kg/60x9Ah ile 235 Kg | 40x9Ah ile 155 Kg/60x9Ah ile 235 Kg | 60x9Ah ile 235 Kg |
| Dimensions (mm) WxDxH | 350 x 785 x 1078 | 350 x 785 x 1078 | 350 x 785 x 1078 |
| Optional | |||
| Temp charge compensation | Charge current compensation accordingly to temperature | ||
| Communication adapters | SNMP, MODBUS, RS485 | ||
| Parallel capacity | up to 6 | ||
