THÔNG SỐ KỸ THUẬT:
| MODEL | HRL110800S | HRL111500S | HRL112000S | HRL114000S | HRL116000S |
| HRL110800L | HRL111500L | HRL112000L | HRL114000L | HRL116000L | |
| Capacity | 800VA | 1500VA | 2000VA | 4000VA | 6000VA |
| Input voltage range | 55VAC-155VAC | ||||
| 100% load@>96VAC; 80% load@>85VAC | |||||
| 70% load@>70VAC; 50% load@>55VAC | |||||
| Input frequency | 40-70Hz | ||||
| Input PF | ≥0.97 | ≥0.99 | |||
| Voltage regulation | ±1 % | ||||
| Output frequency | 50/60Hz | ||||
| Output PF | 0.9 | 0.8 | |||
| Overload capability | 110%: to bypass after 10 min; | ||||
| (Inverter mode) | 105%-130%: to bypass 1 min; | 130%: to bypass after 1 min; | |||
| 150%: to bypass after 30 s | 150%: to bypass after 30 s, shutdown after 1 min | ||||
| Overload capability | 110%: shutdown after 10 min; | ||||
| (Battery mode) | 105%-130%: shutdown after 10 s; | 125%: shutdown after 10 s; | |||
| 150%: shutdown after 5 s | >125%: shutdown after 1 s | ||||
| Crest factor | 3:01 | ||||
| Efficiency | 87% | 91% | 90% | 90% | |
| Display | LED+LCD | ||||
| Battery voltage | 36VDC | 72VDC | 72VDC | 192VDC | |
| Battery type/number | 12V,7Ah*3 | 12V,7Ah*6 | 12V,7Ah*6 | 12V,7Ah*16 | 12V,9Ah*16 |
| External | |||||
| Interface | Standard: RS232, EPO | ||||
| Optional: USB, SNMP, Dry contacts, Battery cabinet, ECO Kit | |||||
| Optional: USB, SNMP, Dry contacts | |||||
| Operation temperature | 0-40℃ | ||||
| Relative humidity | 0-95% (non-condensing) | ||||
| W*D*H (mm) | 440*430*86 | 440*480*173 | 440*480*173 | 438*680*218 | 438*680*218 |
| 440*430*86 | 440*480*86 | 440*480*86 | 438*680*130 | 438*680*130 | |
| Weight (kg) | 11.5 | 25 | 29 | 62 | 70.5 |
| 7 | 8 | 9.5 | 18.5 | 21.5 | |
