THÔNG SỐ KỸ THUẬT:
| MODEL | HR1101S | HR1102S | HR1103S | HR1106XS | HR1110XS |
| HR1101L | HR1102L | HR1103L | HR1106XL | HR1110XL | |
| Capacity | 1kVA | 2kVA | 3kVA | 6kVA | 10kVA |
| Input voltage range | 110VAC-288VAC | ||||
| 100% load@>176VAC; 80% load@>154VAC | 100% load@>176VAC; 90% load@>160VAC | ||||
| 70% load@>132VAC; 50% load@>110VAC | 80% load@>140VAC; 60% load@>110VAC | ||||
| Input frequency | 40-70Hz | ||||
| Input PF | ≥0.97 | ≥0.99 | |||
| Voltage regulation | ±1 % | ||||
| Output frequency | 50/60Hz | ||||
| Output PF | 0.9 | 1 | |||
| Overload capability | 105%-130%: to bypass 1 min; | 110%: for 10 min; | |||
| (Inverter mode) | 150%: to bypass after 30 sec | 125%: for 1 min; | |||
| 150%: for 30sec | |||||
| Overload capability | 105%-130%: shutdown after 10 sec; | 110%: shutdown after 10 min; | |||
| (Battery mode) | 150%: shutdown after 5 sec | 130%: shutdown after 10 sec; | |||
| >130%: shutdown after 200 ms | |||||
| Crest factor | 3:01 | ||||
| Efficiency | 87% | 91% | 90% | 95% | |
| Display | LED+LCD | ||||
| Battery voltage | 36VDC | 72VDC | 96VDC | 192VDC | |
| Battery type/number | 12V,7Ah*3 | 12V,7Ah*6 | 12V,7Ah*8 | 12V,7Ah*16 | 12V,9Ah*16 |
| External | |||||
| Interface | RS232,SNMP | ||||
| Optional | USB, SNMP, ECO kit, Dry contacts, Battery cabinet | ||||
| USB, SNMP, Dry contacts | |||||
| Operation temperature | 0-40℃ | ||||
| Relative humidity | 0-95%(non-condensing) | ||||
| W*D*H(mm) | 440*430*86 | 440*480*173 | 440*480*173 | 440*660*173 | |
| 440*430*86 | 440*480*86 | 440*480*86 | 440*550*86 | ||
| Weight(kg) | 11.5 | 25 | 31 | 59 | 67 |
| 7 | 8 | 9.5 | 17.5 | 20.5 | |
