THÔNG SỐ KỸ THUẬT:
| Model | PG-2 | PG-3 | PG-4 | PG-6 | PG-8 | PG-10 | PG-15 | |||||
| Power 11 Gold | 2200 VA | 3000 VA | 5000 VA | 6000 VA | 8000 VA | 10000 VA | 15000 VA | |||||
| Input | ||||||||||||
| Power Factor | > 0,99 | |||||||||||
| Nominal Voltage | 280 VAC (1 PH+1N) / 280 VAC (1 PH + 1 N) | |||||||||||
| Voltage Tolerance (at full load) | 160 – 280 V | |||||||||||
| Voltage Tolerance (%75 load) | 140 – 208 V | |||||||||||
| Voltage Tolerance (%50 load) | 110 – 280 V | |||||||||||
| Voltage Tolerance (%25 load) | 80 – 208 V | |||||||||||
| Nominal Current | 10A | 14A | 22A | 27A | 34A | 43A | 65A | |||||
| Fequency | 50 Hz +12% | |||||||||||
| Protection | Current limitation on the rectifier input voltage of surge voltage protection, fast-acting fuses | |||||||||||
| Output | ||||||||||||
| Power W | 1980 | 2700 | 4500 | 5400 | 7200 | 7200 | 12000 | |||||
| Power Factor | 0,9 | 0,9 | 0,8 | 0,8 | ||||||||
| Voltage | 220 V AC (Tek fazlı) / 220 V AC (Single-phase) | |||||||||||
| Voltage Tolerance | 1% | |||||||||||
| Frequency | 50 Hz +60 Hz. | |||||||||||
| Frequency Tolerance | +%0,01 | |||||||||||
| Waveform | Full sine wave | |||||||||||
| Transfer Time | 0 ms | |||||||||||
| Efficiency | > %93 | |||||||||||
| THD (at full linear load) | < %3 | |||||||||||
| THD (at full non-linear load) | < %5 | |||||||||||
| Crest Factor | 3:01 | |||||||||||
| Overload Protection | Bypass at 150% overload | |||||||||||
| Short Circuit Protection | Improved reliability with artificial ıntelligence algorithms | |||||||||||
| Communication Interface | RS232 | |||||||||||
| Free cont. relays outputs | Battery Low, Bypass, Output Fault, Input Voltage Fault, Overload (adjustable more) | |||||||||||
| Battery | ||||||||||||
| Number of Batteries | 8 | 8 | 16 | 16 | 16 | 16 | 24 | |||||
| Charging voltage | 110 VDC | 110 VDC | 220 VDC | 220 VDC | 220 VDC | 220 VDC | 220 VDC | |||||
| Dıscharge limit | 84 VDC | 84 VDC | 168 VDC | 168 VDC | 168 VDC | 168 VDC | 168 VDC | |||||
| Back-Up time | 5-960 minutes | 5-720 minutes | ||||||||||
| Battery protection | Automatic circuit breakers | |||||||||||
| Battery Charger | ||||||||||||
| Built in boosted charger | 25A | 25A | 25A | 25A | 25A | 25A | 25A | |||||
| General | ||||||||||||
| Control panel | Digital Liquid Crystal Display (4×20) With Touch-Pad | |||||||||||
| Operating temperature range | 0-40 °C | |||||||||||
| Noise level (in 1m.mesafe) | < 45 dBA | < 45 dBA | < 50 dBA | < 50 dBA | < 50 dBA | < 50 dBA | < 50 dBA | |||||
| Protection class | IP20 | |||||||||||
| Humidity | < %95 | |||||||||||
| Without battery weight (kg) | 26 | 26 | 26,5 | 27 | 30 | 32 | 34 | |||||
| Without battery weight (kg) | (440x590x216) | (440x590x216) | (440x590x216) | (440x700x216) | (440x590x216) | (440x590x216) | (440x700x216) | |||||
