THÔNG SỐ KỸ THUẬT:
| Sn (kVA) | 160 | 200 | 500 |
| Pn [kW] | 160 | 200 | 500 |
| Input / output | 3-Mar | ||
| Parallel configuration | up to 4 MW | ||
| Input | |||
| Rated voltage | 400 V 3ph | ||
| Voltage tolerances | 200 V to 480 V (1) | ||
| Rated frequency | 50 / 60 Hz | ||
| Frequency tolerance | ± 10 Hz | ||
| Power factor/THDI | > 0.99 / < 2.5%(2) | ||
| Output | |||
| Rated voltage | 3ph + N 400 V | ||
| Voltage tolerance static load | ±1% dynamic load in accordance with VFI-SS-111 | ||
| Rated frequency | 50 / 60 Hz | ||
| Frequency tolerance | ± 2% (configurable for GenSet compatibility) | ||
| Total output voltage distortion – linear load | ThdU < 1.5% | ||
| Total output voltage distortion – non-linear load (lEC 62043-3) | ThdU < 3% | ||
| Short circuit current (1) | up to 3.4 x In | ||
| Bypass | |||
| Rated voltage | rated output voltage | ||
| Voltage tolerance | ± 15% (configurable with from 10% to 20%) | ||
| Rated frequency | 50/60 Hz | ||
| Frequency tolerance | ± 2% (configurable for GenSet compatibility) | ||
| Efficiency | |||
| Online mode @ 40 % of load | up to 96% | ||
| Online mode @ 75 % of load | up to 96% | ||
| Online mode @ 100 % of load | up to 96% | ||
| Fast EcoMode | up to 99% | ||
| Environment | |||
| Operating ambient temperature | from 10 °C up to +40 °C (1) (from 15 °C to 25 °C for maximum battery life) | ||
| Relative humidity | 0% – 95% without condensation | ||
| Maximum altitude | 1000 m without derating (max. 3000 m) | ||
| Acoustic level at 1 m (ISO 3746) | <65 dBA | <67 dBA | <72 dBA |
| UPS Cabinet | |||
| Dimensions W x D x H | 700 x 800 x 1930 mm | 1600 x 950 x 1930 mm | |
| Weight | 470 kg | 490 kg | 1500 kg |
| Degree of protection | IP 20 (other IP as option) | ||
| Colours | cabinet: RAL 7012, door: silver grey | ||
| Standards | |||
| Safety | IEC/EN 62040-1, AS 62040.1.1, AS 62040.1.2 | ||
| EMC | IEC/EN 62040-2, AS 62040.2 | ||
| Performance | IEC/EN 62040-3, AS 62040.3 | ||
| Seismic compliance | Uniform Building Code UBC-1997, EN 60068-3-3/1993 (seismic), | ||
| EN 60068-2-6/2008 (sinusoidal), EN 60068-2-47/2005 (mounting). | |||
| Product declaration | CE, RCM (E2376) | ||
