THÔNG SỐ KỸ THUẬT:
| Sn [kVA] | 15 | 20 | 30 | 40 | 60 | 80 |
| Pn [kW] | 13.5 | 18 | 27 | 36 | 54 | 72 |
| Input / output 3/1 | • | • | – | – | – | – |
| Input / output 3/3 | • | • | • | • | • | • |
| Parallel configuration | 1+1(1) | |||||
| Input | ||||||
| Rated voltage | 400 V 3ph + N | |||||
| Voltage tolerances | 240 V to 480 V(2) | |||||
| Rated frequency | 50/60 Hz ± 10% | |||||
| Power factor / THDI | 0.99 / < 3% | |||||
| Output | ||||||
| Rated voltage | 1ph + N: 230 V (can be configured 220/240 V) | |||||
| 3ph + N: 400 V (can be configured 380/415 V) | ||||||
| Voltage tolerance | static load ±1% dynamic load in accordance with VFI-SS-111 | |||||
| Rated frequency | 50/60 Hz | |||||
| Frequency tolerance | ± 2% (configurable from 1% to 8%) | |||||
| Overload | 125% for 10 minutes, 150% for 1 minute | |||||
| Crest factor | 3:01 | |||||
| Bypass | ||||||
| Rated voltage | rated output voltage | |||||
| Voltage tolerance | ± 15% (configurable with from 10% to 20%) | |||||
| Rated frequency | 50/60 Hz | |||||
| Frequency tolerance | ± 2% (configurable for Genset compatibility) | |||||
| Efficiency | ||||||
| Online mode @ 100 % of load | up to 94.5% | |||||
| Environment | ||||||
| Operating ambient temperature | from 0 °C up to 40(2) °C (from 15 °C to 25 °C for maximum battery life) | |||||
| Relative humidity | 0% – 95% without condensation | |||||
| Maximum altitude | 1000 m without derating (max. 3000 m) | |||||
| Acoustic level at 1 m (ISO 3746) | < 52 dBA | < 55 dBA | < 62 dBA | |||
| UPS cabinet | ||||||
| Dimensions W x D x H | 444 x 795 x 800 / 1000 / 1400 mm | 444 x 795 x 1400 mm | ||||
| Weight(3) | 105 kg | 110 kg | 135 kg | 152 kg | 180 kg | 200 kg |
| Degree of protection | IP20 | |||||
| Colours | RAL 7012 | |||||
| Standards | ||||||
| Safety | IEC/EN 62040-1, AS 62040.1.1, AS 62040.1.2 | |||||
| EMC | IEC/EN 62040-2, AS 62040.2 | |||||
| Performance | IEC/EN 62040-3, AS 62040.3 | |||||
| Product declaration | CE, RCM (E2376) | |||||
