THÔNG SỐ KỸ THUẬT:
| MODEL | HT3110L | HT3115L | HT3120L |
| Cold Start | YES | ||
| Default output frequency will be 50Hz or settable | |||
| Acceptable Input Voltage | L-L 190VAC~499VAC | ||
| 100% load@>305VAC | |||
| 90% load@>266VAC | |||
| 75% load@>228VAC | |||
| 50% load@>190VAC | |||
| Phase | Three phase in,single phase out | ||
| Transfer Voltage Range | L-L 380/400/415VAC | ||
| -Line low transfer | 190VAC | ||
| -Line low recovery | 209VAC | ||
| -Line high transfer | 499VAC | ||
| -Line high recovery | 486VAC | ||
| Input Current | |||
| -Rating(nominal input voltage) | 16.5A/380V | 25A/380V | 33A/380V |
| -Input Power Factor | ≥0.99 | ||
| -Input current distortion | ≤4% | ||
| -Input Frequency Range | 40~70Hz | ||
| OUTPUT | |||
| Frequency adaptable | Settable | ||
| Power | |||
| -Power | 10KVA | 15KVA | 20KVA |
| -Power(kW) | 10KW | 15KW | 20KW |
| Output Voltage | |||
| -Waveform(Bat. Mode) | Pure Sine Wave | ||
| -Nominal voltage | L-N 220VAC/230VAC/240VAC, 200VAC/208VAC(PF=0.9) | ||
| -Voltage regulation | ± 1 % | ||
| -Voltage distortion | ≤1% THD, linear load | ||
| ≤3% THD, non linear load | |||
| Output Frequency | |||
| -Synchronization range | ±5Hz default, settable | ||
| -Battery mode | (50±0.1) Hz default | ||
| Transfer Time | |||
| -Line mode to battery mode | 0ms | ||
| -Inverter to bypass | 0ms | ||
| Efficiency | |||
| -Line mode with battery full charged | 94%@100% load, 94.5%@70% load |
94.2%@100% load 95%@70% load |
94.2%@100% load 95%@50% load |
| -ECO mode | 98.0% | ||
| Noise(1m away) | <55dB | <62dB | <62dB |
| Overload Capability(Inverter) | 105% to 110% : Transfer to bypass after 10 mins. | ||
| 111% to 125% : Transfer to bypass after 1 mins. | |||
| 126% to 150%: Transfer to bypass after 30s | |||
| Overload Capability (Bypass Mode) | less than 125%: long time running | ||
| 126% to 130% :Shutdown in 5 mins | |||
| 131% to 150% :Shutdown in 1 mins | |||
| > 150% :Shutdown in 200 ms | |||
| BATTERY | |||
| Quantity | 16-20PCS settable | 16-20PCS settable | 16-20PCS settable |
| DC Voltage | 192VDC default, settable | ||
| Charger | |||
| -Charging current (max) | 5A max,settable | 5A max,settable | 5A max,settable |
| -Float Charging Voltage | 2.25V/cell default, setttable via software | ||
| -Boost Charging Voltage | 2.25V/cell default, setttable via software | ||
| Indicator & Alarm | |||
| -Display | LED+LCD | ||
| Inteface | |||
| -Smart RS232 | Standard Cable support INVT Power Monitor Software | ||
| -EPO | NC, NO settable, forbidden default | ||
| -RS485(option) | Installed in the intelligent slot | ||
| -SNMP(option) | Power Managment from SNMP Manager and Web Browser | ||
| Option | |||
| -Intelligent Kits | DB9 port, dry contact | ||
| -parallel | 4 units paralleled | ||
| -Super charger (12A) | digitally controlled, 4-steps charge, settable | ||
| -USB | B-type USB port | ||
| -SNMP Kits | Pluggable type | ||
| Working Enviroment | |||
| -Storage | |||
| -40~70℃ | |||
| -Working | 0~40℃, huminity 95% non condesation, attitude<3000m (@full load) | ||
| Mechanical | |||
| -W╳D╳H (mm) | 190*485*336 | 190*485*480 | 190*485*480 |
| -Net Weight (KG) | 20 | 30 | 30 |
| -Package Weight (KG) | 22 | 33 | 33 |
| -Rack / Tower | Tower | ||
| Color | Black default | ||
| FUNCTION | Compatible with half wave load | ||
| Main input breaker | |||
| Bypass input breaker | |||
| ECO mode | |||
| Battery cabinet | |||
| Self aging | |||
| Digital Charger | |||
| Remained Battery Capacity | |||
| 12A charger (PF will be de rated to 0.9) | |||
